Description
Maximum external dimensions (excluding all-in-one machine): length 490mm * width 625mm * height 1500mm
Table size: 490mm in length, 480mm in width, with a maximum height of 1095mm from the ground
Whole machine weight: 50KG (excluding all-in-one machine)
Table material: Medical ABS plastic
Base material: one-piece injection molding
Column material: 6063 aviation aluminum alloy
Handle material: ABS plastic at the front and metal at the back
Pull out tray size: length 300mm * width 310mm
Self suction 2-layer drawer
Box size: Width 420mm * Depth 290mm * Height 310mm
Dimensions of the first layer of the drawer: width 315mm * depth 260mm * height 90mm
Drawer second layer dimensions: width 315mm * depth 260mm * height 165mm
• Optional workbench lifting method
Electric button lifting: lifting stroke 250mm (standard)/300mm (optional)
• Monitor stand
1. Monitor mounting holes: 75mm * 75mm, 100mm * 100mm
2. Hengli lifting stroke: 110mm
1. Hand sanitizer rack 2. Scanned gun rack Printer tray 4. Desktop host tray 5. Metal mesh basket
6. ABS storage box 7. Camera bracket 8. Infusion rack 9. Multi country socket 10.220V power supply
Wheels: 4-inch double pedal double row brake wheels or 4-inch single wheel brake wheels
◎ Integrated machine parameters
CPU: Intel Core i5 7th generation
Memory: 8GB
Hard drive: 256GB SSD solid state drive Screen size: 21.5 inches
System: WIN7
Wireless: WiFi6
Optional all-in-one computer: 23.8 inches and above
Battery parameters
Battery cell: lithium iron phosphate
Input (AC): 100~250V
Charging time: less than 6 hours
Output (DC): 19V6A
Battery life: 8-10 hours of operation
Security protection: equipped with overvoltage, overcurrent, undervoltage, overcharge, and overdischarge functions
Charging times: cycle charging times greater than 2000 times
Switch design: Dual switch design to prevent misoperation
